SC Singlemode Simplex Fiber Optic Patch Cord

Model No: LC-SC-MM-DX

Network Simplex Patch Cord With OFNP Jacket Cable Single Mode Fiber Cable

Connector Type : SC

Fiber Type : OS2, Singlemode

Cable Type : SX

Cable OD : 3.0mm

Cable Jacket : PVC/LSZH/OFNP Cable Color Yellow Or Customized
High Light fibre optic patch leads, fiber optic cable patch cord

minimum order :

1000 pieces

Quantity :

add to cart

Contact Now

SC Singlemode Simplex Fiber Optic Patch Cord with OFNP Jacket Cable

Description:
SC Fiber optic patch cord is suited for equipment jumper cable, cross connects, and work area connections.All fiber
optic patch cords are manufactured with telecom class and polished A, and 100% factory tested to ensure
performance to TIA/EIA-568-B-3 standards.Fiber Patch C ords are available in both multimode (62.5/125µm
and 50/125µm) and single mode cable-types, in duplex and simplex versions.

Features:
Price Competitive
Factory-terminated and Tested
Good durability
Good exchangeability
High temperature stability

Application:
Telecom Network
Local Ring Network
Optical Fiber Sensor
Optical Fiber Test Equipment
Optical Fiber Communication System
FTTH,LAN,PON & Optical CATV

Specification:
Fiber Optic Connector Performance Specification:
Network Simplex Patch Cord With OFNP Jacket Cable Single Mode Fiber Cable

Connector Type	FC, SC, LC, ST, MU, MTRJ
Fiber Type	SM(G.652D/G.657A)			MM(OM1/OM2/OM3/OM4)
Ferrule End-face	PC	UPC	APC	UPC
Insertion Loss	≤0.2dB	≤0.2dB	≤0.3dB	≤0.3bB
Return Loss	≥50dB	≥55dB	≥60dB	≥35dB
Exchangeability	≤0.2dB
Repeatability	≤ 0.1dB(1000 times)
Durability	> 1000 times
Operating Temperature	-40°C ~ +85°C

Fiber Optic Cable Performance Specification:

Fiber type	Min. Bandwidth	Distance	Attenuation
62.5/125	850/1300nm 200/500 MHz/Km	@100Mbps 2km @1Gig 220m	850/1300nm 3.0/1.0dB/km
50/125	850/1300nm 500/500 MHz/Km	@100Mbps 2km @1Gig 500m	850/1300nm 3.0/1.0dB/km
50/125 10Gig Optimized	850/1300nm 2000/500 MHz/Km	@100Gig Varies by VCSEL typical 300m 2850nm	850/1300nm 3.0/1.0dB/km
9/125	1310/1550nm Approx 100 Terahertz	Up to 100km Varies by transceiver	1310/1550nm 0.4/0.3dB/km

Order Information:

SC/UPC-SC/UPC-SM-SX-3.0mm-3M
SC	/	UPC	—	SC	/	UPC	/	SM	—	SX	/	3.0	—	3M
1		2		3		2		4		5		6		7
1	Connector#1: LC,SC,FC,ST,DIN,D4,MU,MTRJ,etc.
2	Lapping Way: UPC&APC (For MTRJ, F=Female, M=Male)
3	Connector#2: LC,SC,FC,ST,DIN,D4,MU,MTRJ,Pigtail,etc.
4	Cable Type: SM(9/125μm) ,MM(50/125μm & 62.5/125μm), OM3, OM4
5	Fiber Number: SX(Simplex) or DX(Duplex), 2/4/6/8 core...
6	Cable Diameter: 2.0=Ø2.0mm, 3.0=Ø3.0mm, 0.9=Ø0.9mm, etc.
7	Cable Length: 3m(Length in meter)

SC Singlemode Simplex Fiber Optic Patch Cord Picture:
